Jinko Tiger Neo 475W N Type JKM475N-48QL6-DB (IEC 61215-2021)
Jinko Tiger Neo 475W N Type Mono Facial Dual Glass Panel 30mm/JKM475N-48QL6-DB (IEC 61215-2021)
Item Data
Package Qty and Dimensions:
Wattage:
Item Warranty Detail
25 Years Product Warranty
30 Year Linear Power Warranty
Jinko Tiger Neo 475W N Type JKM475N-48QL6-DB (IEC 61215-2021)
Jinko Tiger Neo 475W N Type Mono Facial Dual Glass Panel 30mm/JKM475N-48QL6-DB (IEC 61215-2021)
Panel Specifications
| Model Id | JKM475N-48QL6-DB |
| Dimension | 1762×1134×30 |
| Weight (kg) | 21.5 |
| Power (W) | 475 |
| Technology | N-Type TOPCon |
| Appearance | Black Frame |
| Description | Monofacial DBL Glass |
| Cell | 48 Half Cut |
| Voc(V) STC | 36.76 |
| Isc(A) STC | 15.98 |
| Isc 1.25 | 19.975 |
| Connector | PV-JK03M, PV-03M2, PV-KST4-EVO2A, PV-KBT4-EVO2A |
| Product Warranty | 25 |
| Performance Warranty | 30 |
| Pallet Qty | 37 |
| Pallet Dimension | 1792*1140*1249 |
| Glass Front | 1.6mm 5400Pa |
| Glass Back | 1.6mm 2400Pa |
Document Downloads
Item Datasheet
